AM3136 | Analog Tunable Filter Bank 8.0 GHz to 19 GHz

Atlanta Micro AM3136

Analog Tunable Filter Bank 8.0 GHz to 19 GHz

Description

AM3136 is a dual MMIC analog voltage-tunable bandpass filter covering the 8.0 to 13.5 GHz and 12.0 to 19.0 GHz frequency ranges. Separate low-pass and high-pass tuning voltages provide independent control of both center frequency and bandwidth. AM3136 is packaged in a 5mm QFN package and operates over the -40 C to +85 C temperature range.

Technical Data

Specification

Insertion Loss (dB) # in package Cutoff Frequency (GHz) Center Frequency (MHz) Typical Rejection (dB) Bandwidth (MHz) Package
+9 2 8.0 to 19.0 Analog Adjustable 50 Analog Adjustable 5 mm x 5 mm QFN

Datasheet
