ARF1206L5 is a packaged low-noise amplifier for E-band applications. With 18 dB typical gain and 3 dB noise figure at 71 GHz, it is suitable for a variety of demanding telecommunication and sensing applications. Amplifier stages 1 and 2 are controlled by a single gate bias connection VG12, whereas a separate gate voltage VG3 controls the output stage. These voltages can be used to control the amplifier gain, to turn the part off, or connected to 0 V for full gain operation. The part is pre-matched to 50 Ω, ESD protected and housed in a laminate package to simplify handling and assembly.
The part is RoHS* compliant and built with the latest manufacturing techniques to optimize for reliability and quality control.
| Frequency (GHz) | Gain (dB) | NF (dB) | P1dB (dBm) | Power Supply
(+V) | (mA) |
Package |
| 71 – 86 | 18 | 3 @ 71 GHz
5 @ 86 GHz |
12 | 4 | 45 |
5x5mm QFN
|
LNA 71 ~ 86 GHz
