The D5601 series from TE Connectivity’s Sensors Business Unit sets the price and performance standard for wireless differential pressure transducers used in demanding industrial and smart factory applications. The modular D5601 wireless pressure transducer uses our Ultrastable MEMS sensing element enclosed in a stainless steel and PBT housing. The high accuracy 24-bit Bluetooth 4.2 connection eliminates hard wiring and enables remote process control and monitoring. This series is suitable for the measurement of gas or liquid pressures including harsh media such as contaminated water, steam, and mildly corrosive fluids. The wetted surfaces of the pressure ports are made from 316L stainless steel. The port design uses no internal O-rings or organics exposed to the pressure media which provides excellent durability and long-term performance.
The D5601 is FM certified for Intrinsic Safety:
| Product Number | Internal Product Number | Pressure | Pressure Accuracy | Operating Temperature Range |
| D5601-000205-005PD | 20014470-14 | .345 bar | ±0.25% FSO | -20 – 70 °C |
| D5601-000205-050PD | 20014470-16 | 3.45 bar | ±0.1% FSO | -20 – 70 °C |
| D5601-000205-500PD | 20014470-18 | 34.5 bar | ±0.1% FSO | -20 – 70 °C |
| D5601-001205-005PD | 20014470-13 | .345 bar | ±0.25% FSO | -20 – 70 °C |
| D5601-001205-050PD | 20014470-15 | 3.45 bar | ±0.1% FSO | -20 – 70 °C |
| D5601-001205-500PD | 20014470-17 | 34.5 bar | ±0.1% FSO | -20 – 70 °C |
| D5601-001305-005PD | 20014470-12 | .345 bar | ±0.25% FSO | -20 – 85 °C |
