The EPL is a surface mount pressure sensor with a stainless steel diaphragm. Available in ranges from 5 to 1000 psi (0.35 to 70 bar), EPL is easy to install on flat surfaces using elastomer or epoxy. Various compensated temperature ranges are available from -40°C up to 90°C.
| Product Number | Internal Product Number | Pressure Type | Output Signal Type | Pressure | Proof Pressure Range |
| EPL-D13-1.5B-/L15M | 20006429-00 | Absolute | 75 mV | 1.5 bar | 3X FS |
| EPL-B01-35B-/L6M/M5M | 20007269-00 | Gauge | 125 mV | 35 bar | 2X FS |
| EPL-B02-7B-/L5M | 20009546-00 | Sealed | 125 mV | 7 bar | 2X FS |
| EPL-D13-3.5B-/L5M | 20012385-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-B02-15B-/L5M | 20013412-00 | Sealed | 125 mV | 15 bar | 2X FS |
| EPL-D13-15B-/L5M | 20013413-00 | Absolute | 125 mV | 15 bar | 2X FS |
| EPL-B03-3.5B-/Z2/L02M/M01M | 20014433-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-D11-0.35B-/Z0/L3M | 20015288-00 | Gauge | 25 mV | .35 bar | 10X FS |
| EPL-D12-0.7B-/Z0/L3M | 20015289-00 | Sealed | 50 mV | .7 bar | 5X FS |
| EPL-D12-7B-/Z2/V5/L5M | 20015421-00 | Sealed | 125 mV | 7 bar | 2X FS |
| EPL-B03-0.35B | 11027401-00 | Absolute | 10 mV | .35 bar | 10X FS |
| EPL-D13-0.35B | 11031615-00 | Absolute | 25 mV | .35 bar | 10X FS |
| EPL-D13-0.35B-/Z2/L4M | 11033433-00 | Absolute | 25 mV | .35 bar | 10X FS |
| EPL-B01-0.35B | 11025803-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-B01-0.35B-/L3M | 11027402-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-B01-0.35B-/M0.3M | 11033020-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-B01-0.35B-/V5 | 11029461-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-B01-0.35B-/Z0 | 11028832-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-B01-0.35B-/Z1 | 11033021-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-B01-0.35B-/Z2 | 11028048-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-B01-0.35B-/Z4 | 11026652-00 | Gauge | 10 mV | .35 bar | 10X FS |
| EPL-D11-0.35B | 11025747-00 | Gauge | 25 mV | .35 bar | 10X FS |
| EPL-B02-0.35B | 11033022-00 | Sealed | 10 mV | .35 bar | 10X FS |
| EPL-D12-0.35B | 11026002-00 | Sealed | 25 mV | .35 bar | 10X FS |
| EPL-D12-0.35B-/Z1 | 11025748-00 | Sealed | 25 mV | .35 bar | 10X FS |
| EPL-B03-0.7B | 11028049-00 | Absolute | 20 mV | .7 bar | 5X FS |
| EPL-D13-0.7B | 11030291-00 | Absolute | 50 mV | .7 bar | 5X FS |
| EPL-D13-0.7B-/Z2/L4M | 11033434-00 | Absolute | 50 mV | .7 bar | 5X FS |
| EPL-B01-0.7B | 11030966-00 | Gauge | 20 mV | .7 bar | 5X FS |
| EPL-D11-0.7B | 11028833-00 | Gauge | 50 mV | .7 bar | 5X FS |
| EPL-B02-0.7B | 11033024-00 | Sealed | 20 mV | .7 bar | 5X FS |
| EPL-D12-0.7B | 11031616-00 | Sealed | 50 mV | .7 bar | 5X FS |
| EPL-D12-0.7B-/Z1 | 11025772-00 | Sealed | 50 mV | .7 bar | 5X FS |
| EPL-B03-1.5B | 11028834-00 | Absolute | 50 mV | 1.5 bar | 3X FS |
| EPL-B03-1.5B-/L3.8M/M0.2M/X | 11029463-00 | Absolute | 50 mV | 1.5 bar | 3X FS |
| EPL-D13-1.5B | 11029464-00 | Absolute | 75 mV | 1.5 bar | 3X FS |
| EPL-D13-1.5B-/Z2/L4M | 11033435-00 | Absolute | 75 mV | 1.5 bar | 3X FS |
| EPL-B01-1.5B | 11033025-00 | Gauge | 50 mV | 1.5 bar | 3X FS |
| EPL-D11-1.5B | 11026654-00 | Gauge | 75 mV | 1.5 bar | 3X FS |
| EPL-D11-1.5B-/L2M | 11024270-00 | Gauge | 75 mV | 1.5 bar | 3X FS |
| EPL-B02-1.5B | 11031617-00 | Sealed | 50 mV | 1.5 bar | 3X FS |
| EPL-D12-1.5B | 11026655-00 | Sealed | 75 mV | 1.5 bar | 3X FS |
| EPL-B03-15B | EPL-15BA-C20001 | Absolute | 125 mV | 15 bar | 2X FS |
| EPL-D13-15B | EPL-15BA-C20003 | Absolute | 125 mV | 15 bar | 2X FS |
| EPL-B01-15B | EPL-15BG-C20001 | Gauge | 125 mV | 15 bar | 2X FS |
| EPL-D11-15B | EPL-15BG-C20003 | Gauge | 125 mV | 15 bar | 2X FS |
| EPL-D11-15B-/Z2 | 10216765-00 | Gauge | 125 mV | 15 bar | 2X FS |
| EPL-D12-15B-/X/L3.5M | EPL-15BS-C10005 | Sealed | 125 mV | 15 bar | 2X FS |
| EPL-B02-15B | EPL-15BS-C20001 | Sealed | 125 mV | 15 bar | 2X FS |
| EPL-D12-15B | EPL-15BS-C20003 | Sealed | 125 mV | 15 bar | 2X FS |
| EPL-D12-15B-/L3M | EPL-15BS-C20007 | Sealed | 125 mV | 15 bar | 2X FS |
| EPL-B02-15B-/L10M | EPL-15BS-C20008 | Sealed | 125 mV | 15 bar | 2X FS |
| EPL-B03-3.5B | 11028836-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-D13-3.5B | 11028053-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-D13-3.5B-/L3M | 11029470-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-D13-3.5B-/Z1 | 11028837-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-B03-3.5B-/Z2 | 11026031-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-D13-3.5B-/Z2/L4M | 11033436-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-D13-3.5B/Z1/L7M | 10219183-00 | Absolute | 100 mV | 3.5 bar | 2X FS |
| EPL-B01-3.5B | 11030294-00 | Gauge | 100 mV | 3.5 bar | 2X FS |
| EPL-D11-3.5B | 11025749-00 | Gauge | 100 mV | 3.5 bar | 2X FS |
| EPL-B02-3.5B | 11029471-00 | Sealed | 100 mV | 3.5 bar | 2X FS |
| EPL-D12-3.5B | 11025836-00 | Sealed | 100 mV | 3.5 bar | 2X FS |
| EPL-B02-3.5B-/Z4 | 10219929-00 | Sealed | 100 mV | 3.5 bar | 2X FS |
| EPL-B03-35B | EPL-35BA-C20001 | Absolute | 125 mV | 35 bar | 2X FS |
| EPL-D13-35B | EPL-35BA-C20003 | Absolute | 125 mV | 35 bar | 2X FS |
| EPL-D13-35B-/Z2 | EPL-35BA-C20005 | Absolute | 125 mV | 35 bar | 2X FS |
| EPL-D13-35B-/Z2/L3M | EPL-35BA-C20006 | Absolute | 125 mV | 35 bar | 2X FS |
| EPL-D13-35B-/Z1 | 10200688-00 | Absolute | 125 mV | 35 bar | 2X FS |
| EPL-B01-35B | EPL-35BG-C20001 | Gauge | 125 mV | 35 bar | 2X FS |
| EPL-D11-35B | EPL-35BG-C20003 | Gauge | 125 mV | 35 bar | 2X FS |
| EPL-D11-35B-/Z4 | 10203929-00 | Gauge | 125 mV | 35 bar | 2X FS |
| EPL-B02-35B | EPL-35BS-C20001 | Sealed | 125 mV | 35 bar | 2X FS |
| EPL-D12-35B | EPL-35BS-C20003 | Sealed | 125 mV | 35 bar | 2X FS |
| EPL-B03-7B-/Z2/V4 | 10221384-00 | Absolute | 125 mV | 7 bar | 2X FS |
| EPL-B03-70B | EPL-70BA-C20001 | Absolute | 125 mV | 70 bar | 2X FS |
| EPL-D13-70B | EPL-70BA-C20003 | Absolute | 125 mV | 70 bar | 2X FS |
| EPL-BO3-70B-/L20M | EPL-70BA-C20004 | Absolute | 125 mV | 70 bar | 2X FS |
| EPL-D13-70B-/Z2 | EPL-70BA-C20006 | Absolute | 125 mV | 70 bar | 2X FS |
| EPL-D13-70B-/Z2/L3M | EPL-70BA-C20007 | Absolute | 125 mV | 70 bar | 2X FS |
| EPL-D13-70B-/Z1 | 10205203-00 | Absolute | 125 mV | 70 bar | 2X FS |
| EPL-B01-70B | EPL-70BG-C20001 | Gauge | 125 mV | 70 bar | 2X FS |
| EPL-D11-70B | EPL-70BG-C20003 | Gauge | 125 mV | 70 bar | 2X FS |
| EPL-D11-70B/Z2/L3M | EPL-70BG-C20004 | Gauge | 125 mV | 70 bar | 2X FS |
| EPL-D11-70B-/SC30M | EPL-70BG-C20005 | Gauge | 125 mV | 70 bar | 2X FS |
| EPL-B02-70B | EPL-70BS-C20001 | Sealed | 125 mV | 70 bar | 2X FS |
| EPL-D12-70B | EPL-70BS-C20003 | Sealed | 125 mV | 70 bar | 2X FS |
| EPL-B02-70B-/M0.3M/L0.5M | EPL-70BS-C20004 | Sealed | 125 mV | 70 bar | 2X FS |
| EPL-B03-7B | EPL-7BA-C20001 | Absolute | 125 mV | 7 bar | 2X FS |
| EPL-D13-7B | EPL-7BA-C20003 | Absolute | 125 mV | 7 bar | 2X FS |
| EPL-D13-7B-/L3M | EPL-7BA-C20004 | Absolute | 125 mV | 7 bar | 2X FS |
| EPL-D13-7B-/Z1 | EPL-7BA-C20006 | Absolute | 125 mV | 7 bar | 2X FS |
| EPL-D13-7B-/Z2/L4M | EPL-7BA-C20007 | Absolute | 125 mV | 7 bar | 2X FS |
| EPL-B01-7B | EPL-7BG-C20001 | Gauge | 125 mV | 7 bar | 2X FS |
| EPL-D11-7B | EPL-7BG-C20003 | Gauge | 125 mV | 7 bar | 2X FS |
| EPL-D11-7B-/Z2/V5 | 10220759-00 | Gauge | 125 mV | 7 bar | 2X FS |
| EPL-B02-7B | EPL-7BS-C20001 | Sealed | 125 mV | 7 bar | 2X FS |
| EPL-D12-7B | EPL-7BS-C20003 | Sealed | 125 mV | 7 bar | 2X FS |
| EPL-D12-7B-/L3M | EPL-7BS-C20005 | Sealed | 125 mV | 7 bar | 2X FS |
| EPL-B02-7B-/Z2/L1M | EPL-7BS-C20006 | Sealed | 125 mV | 7 bar | 2X FS |
